Rockwell Automation RSLogix 5000 Fuzzy Designer User Manual
Page 120
Publication LOGIX-UM004A-EN-P - March 2007
120 FuzzyDesigner Projects
• Zoom out – Zooms out of the graph. The minimum size
depends on maximum (on an absolute scale) value of all
displayed curves.
• Zoom To Fit Window – Changes the graph size to best fit the
window.
• Zoom To Fit Base Vertical Range – Changes the graph size to
best fit the base vertical range in the window.
• Properties – Opens the dialog with graph properties (see Watch
History Graph Properties Dialog).
The second context menu appears you right-click the legend window.
In this menu, you can change the parameters of the curve. The menu
structure is shown in History Graph Legend Context Menu. The menu
items are explained below.
History Graph Legend Context Menu
• Color – Change the color of the selected curve.
• Curve Vertical Range – Opens the dialog for changing the
vertical range of the selected curve (see Curve Vertical Range
Dialog). This range is used to map curves if the graph is relative,
and is valid only for this graph.
Curve Vertical Range Dialog
