3-10 SA3100 Power Modules
.
Table 3.1 – Maximum Recommended Input Line Fuse Ratings
Drive Catalog No.
kW (HP)
Rating
200 - 240V
Rating
380 - 480V
Rating
500 - 600V
Rating
UL Class CC, T, J 1 - BS88 (non-UL installations)
1. Both fast acting and slow blow fuses are acceptable.
SA3100-_001-_ _ 0.75 (1) 10A 6A 6A
SA3100-_003-_ _ 2.2 (3) 15A 10A 10A
SA3100-_007-_ _ 5.5 (7.5) 40A 20A 15A
SA3100-_010-_ _ 7.5 (10) 50A 30A 20A
SA3100-_015-_ _ 11 (15) 70A 35A 25A
SA3100-_020 -_ _ 15 (20) 100A 45A 35A
SA3100-_025 -_ _ 18.5 (25) 100A 60A 40A
SA3100-_030 -_ _ 22 (30) 125A 70A 50A
SA3100-_040 -_ _ 30 (40) 150A 80A 60A
SA3100-_050 -_ _ 37 (50) 200A 100A 80A
SA3100-_060 -_ _ 45 (60) 250A 125A 90A
SA3100-_075 -_ _ 56 (75) - 150A 110A
SA3100-_100 -_ _ 75 (100) - 200A 150A
SA3100-_125 -_ _ 93 (125) - 250A 175A
SA3100-_150 -_ _ 112 (150) - 300A 225A
SA3100-_200 -_ _ 149 (200) - 400A 350A
SA3100-_250 -_ _ 187 (250) - 450A 400A
Bussmann FWP/Gould Shawmut A-70C Semi-conductor Type
SA3100-_300 -_ _ 224 (300) - 450A 400A
SA3100-_350 -_ _ 261 (350) - 500A 450A
SA3100-_400 -_ _ 298 (400) - 600A 500A
SA3100-_450 -_ _ 336 (450) - 800A 600A
SA3100-_500 -_ _ 373 (500) - 800A 800A
SA3100-_600 -_ _ 448 (600) - 900A 800A
SA3100-_650 -_ _ 485 (650) - - 800A
SA3100-_800 -_ _ 597 (800) - 700A 2 700A 2
2. Two fuses in parallel are required.
