MP-Series Medium-inertia Servo Motor with 115 mm to 215 mm Frame Size 3
Rockwell Automation Publication MPM-IN001D-EN-P - January 2014
Catalog Number Explanation
MP M -
x xxx x x - x J 7 x A A
Factory Designated Options
A
= Standard factory configuration
Mounting Flange
A
= IEC metric
Brake
2
= No brake
4
= 24V DC brake
Connectors
7
= Circular, right angle, 180° rotatable
Enclosure/Shaft Key/Shaft Seal
J
= IP65/IP67 housing/shaft key/no shaft seal
Feedback
2
= Resolver
M
= Multi-turn high-resolution encoder
S
= Single-turn high-resolution encoder
Base Speed
B
= 1300 rpm
C
= 1500 rpm
E
= 2250 rpm
F
= 3000 rpm
M
= 4500 rpm
T
= 6000 rpm
Magnet Stacks
1
= 1 stack
2
= 2 stacks
3
= 3 stacks
4
= 4 stacks
Frame Size- Bolt Circle Diameter
115
= 115 mm
130 = 130 mm
165
= 165 mm
215
= 215 mm
Voltage Class
A
= 200V
B
= 400V
Series Type
M
= Medium inertia
Series
MP
=
Premium permanent magnet
rotary servo motor
