18 MP-Series Medium-inertia Servo Motor with 115 mm to 215 mm Frame Size
Rockwell Automation Publication MPM-IN001D-EN-P - January 2014
M23 and M40 Power/Brake Pin Descriptions
Pin MPM- x115x, MPM-x130x, MPM-x165x,
MPM-
x215x
Pin MPM- x165x, MPM-x215x
A Phase U U Phase U
B Phase V V Phase V
C Phase W W Phase W
Ground Ground
E Reserved + BR+
F BR+ - BR-
G BR- 1
Reserved
H
Reserved
2
L M40 Power/Brake Connector
M23 Power/Brake Connector
V
U W
1 2
+
-
A
B C
G
H
E L
F
