Interface adapter connectors, Trusted, Communication interface t8151b – Rockwell Automation T8xxx Trusted Communications Interface User Manual
Page 59
Trusted
TM
Communication Interface T8151B
Issue 21 Apr 10
PD-T8151B
59
6.5. Interface Adapter Connectors
Table 23 below gives a list of connectors required to interface to the Communications Interface
Interface Adapter (T8153).
Connection
Manufacturer
Part Number
Bank 1, Full RS232
(9 –way socket)
Phoenix Contact
18 81 39 6
Bank2 , Part RS232 and all
RS485
(5-way socket)
Phoenix Contact
18 81 35 4
Ethernet 1 & 2, 10BaseT*
(RJ45 plug)
Molex
Stewart
Amp
87281-8003
940-SP-3088R
55541693
Ethernet 1 & 2, 10Base2*
(BNC Plug, 50R)
Ma-Com (crimp connection)
Multicomp (crimp
connection)
Ma-Com (clamp connection)
B35A41JB10X99
1310F1RG58
B35A70E10X99
Ethernet 1 & 2, 10Base2*
(Adaptors, 50R)
Ma-Com (T-adaptor)
Multicomp (T-adaptor)
Multicomp (F-adaptor)
VBA109
13392DGN
VBA112
Note:
Items marked * show a selection of manufacturers for these parts. These are standard parts and the manufacturers listed here
are not the only ones that can be used. Note that different crimp tools will be required for different manufacturers’ parts. The
10/100BaseT and 10Base2 cables can also be bought ready-made.
Table 23 Interface Adapter Connectors
