A-2
Busbar Splice Kit Catalog
Numbers Power Bus Splice Kit Catalog Numbers
Table A.A Power Bus Splice Kits
Table A.B Special Power Bus Splice Kits For Splicing to a Common AC Bus
F-Frame 2362 Unit, Any G-Frame 2362 Unit, or Any M or N-Code 2364F Unit
Control Bus Splice Kit Catalog Numbers
Table A.C Control Bus Splice Kits
PE/TE Bus Splice Kit Catalog Numbers
Table A.D PE/TE Bus Splice Kits
If: Then select the appropriate kit from:
You are splicing directly to a common
AC bus F-frame, any G-frame 2362
unit, or any M or N-code 2364F unit Table B
Otherwise Table A
Power Bus Power Bus
Rating AC Common Bus DC Common Bus
(Amps) Straight Splice Kit Offset Splice Kit Straight Splice Kit Offset Splice Kit
800 2300H-SKA-L08 2300H-SKA-Z08 2300H-SKD-L08 2300H-SKD-Z08
1200 2300H-SKA-L12 2300H-SKA-Z12
1600 2300H-SKA-L16 2300H-SKA-Z16 2300H-SKD-L16 2300H-SKD-Z16
2000 2300H-SKA-L20 2300H-SKA-Z20
3000 2300H-SKA-L30 2300H-SKA-Z30 2300H-SKD-L30 2300H-SKD-Z30
Power Bus Power Bus
Rating AC Common Bus DC Common Bus
(Amps) Straight Splice Kit Offset Splice Kit Straight Splice Kit Offset Splice Kit
800-3000 2300H-SKA-L30S 2300H-SKA-Z30 2300H-SKD-L30S 2300H-SKD-Z30
Power Bus Rating Control Bus
(Amps) Straight Splice Kit Offset Splice Kit
800-3000 2300H-SKC-L 2300H-SKC-Z
Power Bus Rating (Amps) PE/TE Bus Splice Kit
800-3000 2300H-SKG-30
