Chapter

Installing Busbar Splices

Introduction

This chapter provides the necessary steps to install power, control,
equipment grounding conductor (PE), and zero potential (TE) bus splices.

Before You Begin

Before you begin your installation:

1. Verify that MCCs have been joined together as specified by instructions

provided in Chapter 1.

2. Be sure you have the following:

• One PE / TE (equipment grounding conductor / zero potential) bus splice

kit for every two sections just joined.

• One control bus splice kit, if both sections have a control bus, for every

two sections just joined.

• One power bus splice kit for every two sections just joined.

• Tool(s) you will need to:

– tighten screws:

1/4” thread-forming screw (0.375” across flats)

– torque bolts:

1/4” bolt (0.438” across flats)

– secure screws and nuts:

1/4” nut (0.438” across flats)
3/8” nut (0.563” across flats)
