Completing the Inside of an MCC: Roll-Out Chassis Units
1. Install the horizontal bus access cover. Each horizontal bus access cover
is secured with two screws (see Figure 1.4).
2.
Completing the Inside of an MCC: Bucket Units
1. Install the splice-opening cover on the joining side of the MCC (see
Figure 1.6).
2.
Completing the Inside of an MCC: Panel-Mounted Units
1. Install the horizontal bus access cover (see Figure 1.7).
2. Go to Completing the Outside of an MCC.
If the MCC contains a: Then:
A 2362 (D or E-frame) or 2364F
(K or L-code) roll out chassis unit. 1.Follow the procedures in Chapter 3 to install
the roll-out chassis from the MCC.
2.Go to Completing the Output of an MCC
(page 1-14).
A 2362 (F or G-frame) or 2364F
(M or N-code) roll-out chassis unit. Go to Completing the Outside of an MCC
(page 1-14).
If the MCC will be spliced on: Then:
Right side 1.Close the vertical wireway door and secure the
door by tightening the 3 screwlatches (Figure
1.5).
2.Go to Completing the Outside of an MCC.
Left side 1.Follow the procedures in Chapter 2 to remove
any buckets that were removed.
2.Go to Completing the Outside of an MCC
(page 1-14).
