Rockwell Automation Publication 2100-IN060D-EN-P - March 2014 11
CENTERLINE 2100 Motor Control Center (MCC) Units with Horizontal Operating Handles
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at
http://www.rockwellautomation.com/literature/ . To order paper copies of
technical documentation, contact your local Allen-Bradley® distributor or
Rockwell Automation sales representative.
TIP When properly latched, the slots on all of the arc resistant latches are
vertical and the latch springs are compressed. The spacing of the spring
coils is decreased.
Uncompressed
Spring, Unlatched
Compressed
Spring,
Latched
Resource Description
CENTERLINE 2100 Low Voltage Motor Control Centers
Instruction Manual, publication
2100-IN012
Provides general instructions for MCC Units.
CENTERLINE 2100 Motor Control Center Units with
Vertical Operating Handles, publication
2100-IN014
Provides information on installing units with vertical
operating handles.
Safety Guidelines for the Application, Installation,
and Maintenance of Solid- state Control Installation
Instructions, publication
SGI-1.1
Provides safety guidelines for the application, installation,
and maintenance of solid-state control.
Industrial Automation Wiring and Grounding
Guidelines, publication
1770-4.1
Provides general guidelines for installing a Rockwell
Automation® industrial system..
Product Certifications website, http://
www.rockwellautomation.com/products/
certification
Provides declarations of conformity, certificates, and other
certification details.
