VersaView 1200P Integrated Display Computers for Hazardous Locations 11
Publication 6183H-IN001E-EN-P - July 2007
Panel Mounting Guidelines
Observe the following precautions when installing the computer in a panel.
• Confirm that there is adequate space behind the panel.
• Supporting panels should be at least 14 gauge to ensure proper sealing
against water and dust and to provide proper support. The mounting
hardware supplied accommodates panels up to 6 mm (0.24 in.) thick.
Install the Computer in a Panel
Follow these directions to install the computer in a panel using mounting clips.
1. Cut an opening in the panel using the appropriate panel cutout dimensions.
2. Make sure the sealing gasket is properly positioned on the computer.
3. Place the computer in the panel cutout.
IMPORTANT Supporting panels must be cut to specifications before installation.
ATTENTION
Disconnect all electrical power from the panel before making cutout. Make
sure the area around the panel cutout is clear. Take precautions so that metal
cuttings do not enter any components that are already installed in the panel.
Failure to follow these warnings may result in personal injury or damage to the
panel components.
IMPORTANT This gasket forms a compression type seal. Do not use sealing compounds.
