24
Publication 2711-6.0.4
Electronic Data Sheet (EDS) File
Error Messages
PanelBuilder Device Error
Messages
Reference # Message Recommended Action
1 Could not allocate memory. The system cannot allocate enough memory to read the EDS
file.
2 In order to support scaling, the PV Data Type will be changed to
Unsigned Integer. The chosen parameter has scaling factors. To support scaling
factors, an appropriate PV Data Type must be chosen. The
scaling factor will be calculated and entered as the Scale and
Offset values on the Tag Form.
3 Invalid EDS File. The EDS file is corrupt or contains too many parameters to be
read.
4 The DeviceNet Data Type (#) does not match the PanelView Data Type
chosen. It is recommended that either Bool or Bit Array is chosen. Boor or Bit Array is the best choice for the parameter chosen.
5 The DeviceNet Data Type (#) does not match the PanelView Data Type
chosen. It is recommended that Floating Point is chosen. IEEE Float is the best choice for the parameter chosen.
6 The DeviceNet Data Type (#) does not match the PanelView Data Type
chosen. It is recommended that either Signed or Unsigned Integer is
chosen. Display value scaling may be necessary. Signed or Unsigned Integer is the best choice for the parameter
chosen.
7 The DeviceNet Data Type (#) is unsupported by PanelView. Use of this
parameter may produce unexpected results. There is no corresponding PV Data Type for the DeviceNet
parameter chosen. This parameter requires knowledge of how
the DeviceNet data is structured. For instance, one element of
the DeviceNet Time Data Type may be displayed, but the
location of the internal fields must be known.
8 This parameter designates that extended precision scaling should be
used to display the parameter. PanelView does not support extended
precision scaling. The chosen parameter specifies Extended Precision Scaling.
The appropriate scaling factor must be manually determined
and entered into the Scale and Offset fields of the Tag Form.
9 Unable to open EDS File. The system was unable to open the specified EDS file.
Reference # Message Recommended Action
1 Device: - Cannot be converted to current protocol
format. Create a new device entry in the Terminal Setup dialog.
2 Device: - Communication settings have never been
initialized. Update the Communications Setup dialog to the appropriate
network values (node address, baud rate).
3 Device: - Converted to DeviceNet. Default communi-
cation parameters will be used. Update the Communications Setup dialog to the appropriate
network values (node address, baud rate).
