23
Publication 2711-6.0.4
22 Tag: - Invalid Data Size. Data element extends beyond
input or output size. Increase the input or output size on the terminal setup screen.
23 Tag: - Invalid Element Number The Tag Address must have a numeric word offset.
24 Tag: - Invalid Node Address. Node must be 0 - 63. DeviceNet node addresses must be 0 - 63.
25 Tag: - Invalid Packet Length. Packet Length must be 1-
128 bytes. Change packet bytes to 1-128 bytes.
26 Tag: - Output Element Extends Beyond Output Size. The word offset in the Tag Address must be less than then the
Output Size specified in the Communications Setup dialog.
27 Tag: - The length of the data extends beyond the size of
the packet. If the associated tag is an I/O tag, increase either the Input or
Output Size. If the associated tag is Explicit-Server, the data
extends beyond the 64 word limit of the Assembly Instance.
28 Tag: - The length of the data extends beyond the size of
the packet. Adjust Packet Bytes to at least #. Increase the Packet Bytes assigned to the tag.
29 Tag: - This tag cannot be assumed consistent or
‘atomic’. The Assembly Instance is inconsistent with previous tags in
this group. Tags have been assigned to a PanelBuilder control that must be
updated in the same data packet. Change the Assembly
Instance so it is the same as the other members of this group.
30 Tag: - This tag cannot be assumed consistent or
‘atomic’. The Peer’s Class, Instance, Attribute, or Node Address is
inconsistent with previous tags in this group. Tags have been assigned to a PanelBuilder control that must be
updated in the same data packet. Change the Explicit-Client
message so that it references the same peer attribute as other
tags assigned to this group.
31 Tag: - This tag cannot be assumed consistent or
‘atomic’. The tag’s Message Type is inconsistent with the previous
tags in this group. Tags have been assigned to a PanelBuilder control that must be
updated in the same data packet. Change the Message Type so
that it is the same as the other members of this group.
Reference # Message Recommended Action
