7--2 Using ODS Communication Configuration
Publication 8520--UM051A--EN--P -- October 2000
Offline Development Manual (ODS) Software User Manual
Initial project definitions include the new project’s name, control
family, and communication mode. Figure 7.1 describes the menus
you see when you select:
• communication
mode
• processor type • driver type
Figure 7.1
Communication Selection Flow Chart
1. Select the desired communication mode:
- Control serial port using RS-232 or RS-422
- DH+ network, indirectly to the control, through the PLC backplane
- [ESC], which leaves the current communications type unchanged
- PLC 5/10
- PLC 5/12
- PLC 5/15
- PLC 5/25
2. Select the driver type that ODS will use to communicate over the Data
Highway+. This must match the type of hardware or communications
software installed in the system. The default is 1784-KTK1 for IMC
controls, and INTERCHANGE for 9/Series CNCs using DOS or
Windows 95. For PCs using Windows NT, the default is RSLinx..
Communications
Communication Mode
Driver Type
1784-KT Driver
1784-KL Driver
1784-KTK1 Driver
Serial Port
INTERCHANGE for DH+
(CNCs only)
Processor Type
- PLC 5/250
Done
RSLinx for Ethernet
RSLinx for DH+
(CNCs only)
(IMCs only)
(IMCs only)
(IMCs only)
(IMCs only)
Refer to page 7- 3.
Refer to page 7- 3.
Refer to page 7- 9.
Refer to page 7- 7.
Refer to page 7- 11.
Refer to page 7- 10.
Refer to page 7- 12.
Serial
Ethernet
INTERCHANGE
RSLinx
KTK1, KL, KT, Serial
DH+
3. Select the PLC processor type that ODS will communicate with
to transfer data to the IMC control:
Selecting the
Communication Code
