2 - what you need, Chapter objectives, Personal computer requirements – Rockwell Automation 2706-NP3 DL20 OFFLINE PROGRAMMING MANUAL User Manual
Page 8: Dl20 programming software, What you need
A–B
2
Chapter
2–1
What You Need
This chapter describes the items needed to run the DL20 Offline
Programming Software including:
•
Personal Computer Requirements
•
DL20 Programming Software
•
DL20 Dataliner Message Display
•
Data Recorder
•
Download Cable
The DL20 Programming Software runs on the following computers:
•
IBM PC/XT/AT or 100% compatible
Allen-Bradley T45 and T50 Industrial Computers
Allen-Bradley 6120, 6121 and 6122 Industrial Computers
•
One or two floppy drives (720K minimum)
•
Hard drive is recommended and required on computers with only 1
floppy drive
•
448K of RAM
•
DOS 3.0 or later
•
Serial port on Com1 or Com 2
•
Printer port to print messages
•
Monochrome or color monitor
The DL20 Offline Programming Software is an optional package used to
create messages for the DL20 Dataliner Message Displays. You need version
4.2 or higher. The software is provided on 5
1
/
4
and 3
1
/
2
inch diskettes.
Chapter Objectives
Personal Computer
Requirements
Personal Computer
DL20 Programming Software
DL20 Software
