Message Operations
Chapter 5
5–5
Table 5.A
Message Attributes
Attri ute
DL20 Line #
Vali esponses Attribute
1 2 4
Valid Responses
Auto Clear x x x Y or N
Auto Repeat x x x Y or N
Chain Message x x x Y or N
Energize Relay x x x Y or N
Flash Message x x x Y or N
Invisible Message x x x Y or N
Message Number
(for chaining to) x x x 1 to 254
Out to Slave x x x Y or N ➀
Print Message x x x Y or N ➀
Scroll Mode x x x Y or N ➂
Slave Number x x x 1 to 127 ➃
Stack Message x x x Y or N
To All Slaves x x x Y or N
Use All Lines x x Y or N ➁➂
Use Line 1 Only x x Y or N ➁
Use Line 2 Only x x Y or N ➁
Use Least-Used Line x x Y or N ➁
Use Line 3 Only x Y or N ➁
Use Line 4 Only x Y or N ➁
Wait Time x x x 0 to 31
➀ The Print Message and Out to Slave attributes are mutually exclusive. The DL20 serial port
can only be used for one function at a time. If one is set to Y, the other becomes N.
➁ Only one line attribute can be set to Y.
➂ If Scroll Mode is set to Y, Use All Lines is automatically forced to N.
➃ Slave Numbers 0,4,6,7,13,18,20,22,43,45, and 48–57 are illegal entries.
