Rockwell Automation Publication 2090-IN050B-EN-P - July 2014 17
2090-Series Motor/Actuator Cables
The right-angle feedback cable can be rotated 124° to the left of center or 200° to
the right of center. Follow these steps to rotate the feedback cable connector.
1. Mount the cable on the motor connector.
2. Use two hands to rotate the connector into position.
a. Grasp the front and rear sections of the connector.
b. Use one hand to stabilize the front section of the connector (the area
with the knurled locking sleeve) and the connector on the motor.
c. Use your other hand to rotate the back section of the connector (the
area with the cable) into position.
Table 17 - Right-angle Feedback Cable Pinout
Feedback Cable Type Cable Cat. No. Description
Right-angle feedback cable
(standard, non-flex)
2090-CFBM7DF-CERA
xx
9
10
11
12
13
14 15
16
17
2
3
4 5 6 7 8
1
1
2
3
4
5
6
9
10
11
13
14
12
Rotation Point
Wire Connection Twisted Wire Pair
Black
White/Black
Red
White/Red
Green
White/Green
Gray
White/Gray
Orange
White/Orange
Drain
SIN+/AM+
SIN-/AM-
COS+/BM+
COS-/BM-
DATA+/IM+/R1
DATA-/IM-/R2
EPWR 9V DC
COM
EPWR 5V DC
TS+
TS-
COM
