Terminaux PanelView 1400
23
Connexion de l’alimentation c.a.
Le tableau ci-dessous indique les spécifications électriques pour les terminaux
PanelView 1400.
Type de terminal
Tension
Consommation
PV1400
85 à 264 V c.a.,
47 à 63 Hz
200 VA maximum
Le terminal PanelView 1400 répond aux normes CEI 1131-2 Equipement Classe I
et exige que la borne
(terre de protection) soit connectée à une masse terre.
!
ATTENTION:
Le terminal PanelView 1400 est conçu pour une
utilisation sûre quand il est installé dans une armoire aux normes NEMA
Type 12, 13, 4X (en intérieur uniquement), IP54 ou IP65.
!
ATTENTION
: Ne pas appliquer de tension au terminal tant que toutes
les connexions n’ont pas été câblées. Procéder différemment pourrait
entraîner des décharges électriques.
