Zone Control I/O Cards 5
Publication 1799-IN007D-EN-P - October 2005
Install the Card
To install the card:
• Set the node address
• Mount the card (brackets, mounting plate)
• Connect the card (DeviceNet network, auxiliary power, I/O)
• Communicate with your card
• Configure the parameters
More detailed information about each of these steps is in the following procedures.
Prevent Electrostatic Discharge
Set the Node Address
Valid node addresses are 00 to 63.
Set the node address using the rotary switches or a DeviceNet configuration tool such as
RSNetWorx for DeviceNet software. Setting the switches between 64 and 99 lets the software
have address control.
ATTENTION
This equipment is sensitive to electrostatic discharge, which can cause
internal damage and affect normal operation. Follow these guidelines
when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• If available, use a static-safe workstation.
• When not in use, store the equipment in appropriate static-safe
packaging.
IMPORTANT
You must use RSNetWorx for DeviceNet software, revision 3.21 or later
with the Zone Control I/O cards.
