Zone Control I/O Cards 15
Publication 1799-IN007D-EN-P - October 2005
Use the descriptions in the following table to help you configure the non-DeviceLogix
parameters.
These DeviceLogix capable cards have additional parameters that are described in the
DeviceLogix User Manual, publication number ACIG-UM001, and in the Embedded I/O for
DeviceNet Technical Data, publication number 1799-TD001.
Parameter
Description
Baud Rate
Controls the card’s communication rate.
AutoBaud
Enables the card to match the network’s communication rate. When
enabled, Baud Rate parameter is ignored.
Input Off-to-On
Filter Time
Controls the amount of time the input must be in the on state before
the card reports the input as on.
Input On-to-Off
Filter Time
Controls the amount of time the input must be in the off state before
the card reports the input as off.
Output Idle State
Controls the state of each output when the DeviceNet master is in an
idle state.
Output Fault State
Controls the state of each output when the card loses communication
with the DeviceNet master.
Output Idle Value
Controls the value that outputs will have when the output idle state is
set to use idle value.
Output Fault Value
Controls the value that outputs will have when the output fault state
is set to use fault value.
