Zone Control I/O Cards 17
Publication 1799-IN007D-EN-P - October 2005
Card Status Indicator (Labeled MOD)
Network Status Indicator (Labeled NET)
DeviceLogix Status Indicator (Labeled DS2)
Auxiliary Power Indicator (Labeled AUX PWR)
Indication Status
None No power
Green
Blinking
Solid
Needs commissioning
Device operational
Red
Blinking
Solid
Minor fault
Critical fault
Indication Status
None Not on-line
Green
Blinking
Solid
On-line/no connections
On-line/connected
Red
Blinking
Solid
Connection timed out
Failed communication: a duplicate
node address exists or card is at
the wrong communication rate
Indication Status
None Logic disabled
Green
Solid
Blinking
Logic enabled
Local forces applied and local logic enabled
Indication Status
None No auxiliary power
Green Auxiliary power present
