Entering the special functions menu – Rockwell Automation 2706-DXX Dataliner Message Display DL5 Series User Manual
Page 67

2706-UM001A-US-P
Special Functions
8-3
Entering the Special Functions
Menu
To enter the special functions menu, follow the steps below.
1.
Make sure the RUN? prompt is displayed:
Note: To get the RUN? prompt from the run mode, press [Esc] three times.
From Edit mode it is also necessary to answer [N] to EDIT? and SPECIAL
FUNC?.
2. Press the [N] and [Retrn] keys. The DL5 displays:
3. Press the [N] and [Retrn] keys. The DL5 displays
4. Press the [Y] and [Retrn] keys to enter the Special Functions menu. The
DL5 displays:
The set port prompt is the first special function. To enter the set port
function press the [Y] and [Retrn] keys. To enter one of the other four
special functions, press the [Retrn] key until the special function that you
want is displayed ([N] is the default).
RUN?
EDIT?
SPECIAL FUNC?
SET PORT?N
