Editing message attributes – Rockwell Automation 2706-DXX Dataliner Message Display DL5 Series User Manual
Page 42

2706-UM001A-US-P
4-6
Reviewing and Editing Messages
Editing Message Attributes
To edit the previously entered attributes of a message, perform the
following steps:
1. Make sure the following prompt is displayed:
Note: To get to the EDIT? prompt from the Run Mode, press [Esc] three
times, answer [N] to RUN?, and press [Retrn].
2. Press the [Y] and [Retrn] keys to enter the edit mode. The DL5 will
display:
3. Enter the message number of the message you want to edit and then
press the [Retrn] key. The DL5 will display a portion of the message.
4. Press the [Ctrl] and [A] keys.
– If you are using a one line display, the DL5 will display:
– If you are using a two line display, the DL5 will display:
5. You can now change message attributes by entering new [Y] or [N]
responses to the message attribute prompts and then pressing the [Retrn]
key. Or you can keep the original attributes by pressing the [Retrn] key.
The attribute prompts will appear in the same sequence as when they
were first entered.
EDIT?
NUMBER: 0
SCROLL MODE?
USE BOTH?
