Page 103: Abbreviations
2706-UM001A-US-P
Appendix
B
Cabling Diagrams
Abbreviations
The following table describes the abbreviations used in this appendix.
Allen-Bradley T3 Terminal
Serial Communications Cable
(Catalog No. 2706-NC15)
Allen-Bradley T3 Cable
Abbreviation
Signal
CTS
Clear to Send
DCD
Data Carrier Detect
DSR
Data Set Ready
DTR
Data Terminal Ready
COM
Signal Common
RI
Ring Indicator
RTS
Request to Send
RXD
Received Data
TXD
Transmitted Data
*=Gender specified is for cable connectors
DCD 1
TXD 2
RXD 3
DTR 4
COM 5
DSR 6
RTS 7
CTS 8
8 DCD
3 TXD
2 RXD
20 DTR
7 COM
6 DSR
4 RTS
5 CTS
DL5 Serial Port Female
DB-9* Connector
Allen-Bradley T3 Terminal Male
DB-25* Connector
1 Chassis Ground
