4 ArmorPoint I/O Modules with 8 Configurable 24V DC Points and DeviceLogix
Publication
1738-IN027B-EN-E - February 2010
About the Module
The ArmorPoint I/O family consists of modular I/O modules. The sealed
IP67 housing of these modules requires no enclosure. Note that
environmental requirements other than IP67 may require an additional
appropriate housing. I/O connectors are sealed M8 (pico), M12 (micro) or
M23 styles. The mounting base ships with the module.
MOD
NET
1738-8CFGDLXM8
24V DC
0
1
2
3
4
5
6
7
0
1
2
3
4
5
6
7
1738-8CFGDLXM23
24V DC
MOD
NET
0
1
2
3
4
5
6
7
1738-8CFGDLXM12
24V DC
MOD
NET
0
1
2
3
4
5
6
7
A
H
B
G
C
F
D
E
Connector M8-A
LED Indicators
44929
1738-8CFGDLXM8
Connector M8-B
Connector M8-G
Connector M8-H
1738-8CFGDLXM12
1738-8CFGDLXM23
44927
44928
LED
Indicators
LED
Indicators
Connector M8-C
Connector M8-E
Connector M8-F
Connector M8-D
M23
Connector
Connectors
M12-A...D
Connectors
M12-E...H
