ArmorPoint I/O Modules with 8 Configurable 24V DC Points and DeviceLogix 11
Publication
1738-IN027B-EN-E - February 2010
You can select other produced assemblies:
• Produced assembly instance 4 is the first byte of produced assembly
instance 101 (Data [0]).
• Produced assembly instance 111 is the first eight bytes of produced
assembly instance 101 (Data [0]…[7]).
In RSLogix5000, the default tags will be:
• AdapterName:SlotNumber:I.Data
• AdapterName:SlotNumber:I.LogicDefinedData
• AdapterName:SlotNumber:I.Status.LogicEnabled
• AdapterName:SlotNumber:I.Status.Owned
• AdapterName:SlotNumber:I.PeerMissing
• AdapterName:SlotNumber:I.LogicDefinedIntData[0...7]
Default Data Map - Consumed Assembly Instance 102
Message Size: 20 Bytes
Bit
7
6
5
4
3
2
1
0
Data [0]
Pt 07
PT 06
Pt 05
Pt 04
Pt 03
Pt 02
Pt 01
Pt 00
Data [1]
CNB 07
CNB 06
CNB 05
CNB 04
CNB 03
CNB 02
CNB 01
CNB 00
Data [2]
Reserved
Data [3]
Data [4]
Consume Network Analog Word 0
Data [5]
Data [6]
Consume Network Analog Word 1
Data [7]
Data [8]
Consume Network Analog Word 2
Data [9]
Data [10]
Consume Network Analog Word 3
Data [11]
