10 ArmorPoint I/O Modules with 8 Configurable 24V DC Points and DeviceLogix

Publication

1738-IN027B-EN-E - February 2010

Default Data Map - Produced Assembly Instance 101

Message Size: 20 Bytes

Bit

7

6

5

4

3

2

1

0

Data [0]

Pt 07

PT 06

Pt 05

Pt 04

Pt 03

Pt 02

Pt 01

Pt 00

Data [1]

PNB 07

PNB 06

PNB 05

PNB 04

PNB 03

PNB 02

PNB 01

PNB 00

Data [2]

Reserved

Owned

LogicEn

Data [3]

PM 7

PM 6

PM 5

PM 4

PM 3

PM 2

PM 1

PM 0

Data [4]

Produced Network Analog Word 0

Data [5]

Data [6]

Produced Network Analog Word 1

Data [7]

Data [8]

Produced Network Analog Word 2

Data [9]

Data [10]

Produced Network Analog Word 3

Data [11]

Data [12]

Produced Network Analog Word 4

Data [13]

Data [14]

Produced Network Analog Word 5

Data [15]

Data [16]

Produced Network Analog Word 6

Data [17]

Data [18]

Produced Network Analog Word 7

Data [19]

Where:

Pt = state of the input point

PNB = Produce Network Bit

PM = Peer Missing (each bit represents the presence of a configured peer)

LogicEN = Logic Enabled (0 = logic disabled, 1 = logic enabled)

Owned = owned by a master

When set to 0, the module is producing data without a master.

When set to 1, the module is producing while being owned by a master.
