12 ArmorPoint I/O Modules with 8 Configurable 24V DC Points and DeviceLogix
Publication
1738-IN027B-EN-E - February 2010
You can select other consumed assemblies:
• Consumed assembly instance 34 is the first byte of consumed
assembly instance 102 (Data [0]).
• Consumed assembly instance 112 is the first eight bytes of consumed
assembly instance 102 (Data [0]…[7]).
In RSLogix5000, the default tags will be:
• AdapterName:SlotNumber:O.Data
• AdapterName:SlotNumber:O.LogicDefinedData
• AdapterName:SlotNumber:O.LogicDefinedIntData[0...7]
Data [12]
Consume Network Analog Word 4
Data [13]
Data [14]
Consume Network Analog Word 5
Data [15]
Data [16]
Consume Network Analog Word 6
Data [17]
Data [18]
Consume Network Analog Word 7
Data [19]
Where:
Pt = state of the input point
CNB = Consume Network Bit
Data Map - Configuration Assembly 123
Message Size: 48 Bytes
Bit
7
6
5
4
3
2
1
0
Data [0]
Group Off2On Input filter
Data [1]
Data [2]
Group On2Off Input filter
Data [3]
Default Data Map - Consumed Assembly Instance 102
