Page 27

Manage tasks Chapter 1
2. Enter task information in the New Task dialog box.
Topic
Description
Name
Type a name for the task.
Description
Type an optional description for the task.
Type
Choose Event for the task type.
Trigger
Choose a trigger for the task.
Tag
Choose a tag if the field is active for the selected trigger.
Execute Task If No Event Occurs Within
Select the check box and type a time period that must elapse
before a task can run.
Priority
Enter the task priority value.
Watchdog
Type the watchdog time for the task.
3. Click OK.
Create a periodic task
A periodic task performs a function or functions at a specific rate.
Important: Be sure that the time period is longer than the sum of the run times of all the programs assigned to the task.
•
If the controller detects that a periodic task trigger occurs for a task that is already operating, a minor
fault occurs (overlap).
•
Priorities and run times of other tasks may also cause an overlap.
Rockwell Automation Publication 1756-PM005-EN-P - October 2014
27
