ArmorBlock MaXum 16 Input Module with Complete Diagnostics 13
Publication 1792D-IN053A-EN-P - August 2002
The following table describes logic status indicators.
The following table describes individual I/O status indicators.
For more information on indications see the Technical Data
publication 1792-TD001.
Specifications
Net/Mod Status Indicator
Indicator
Status
Solid Red
Unrecoverable fault
Communication failure - duplicate node address present or incorrect
baud rate
Green to Red to Off At powerup only - LED test
Logic Status Indicators
State
Status
Off
Logic is disabled
Solid Green
Logic is enabled
Flashing Green
Local forces are applied and local logic is enabled
I/O Status Indicators
Function
Module Status Indicator
Point Indicator Condition
Inputs
Green
Green
Module status blink red
Module Status blink red
None
Yellow
Red
1
Blink Red
1
No valid input
Valid input
Short on input A or B
Off-Wire on input A or B
1
The top LED of the pair associated with a connector will provide the diagnostic indicator.
Individual diagnostic information is produced over DeviceNet.
16 Input Module - Cat. No. 1792D-16BVTOCD
Input Specifications
Max.
Min.
Inputs per block
16 - 3 wire or dry contact PNP or NPN devices or 8 - 4 wire
PNP or NPN devices
Sensor Source Current (per input)
50mA
On-state Voltage - Sinking
25V dc
10V dc
On-state Voltage - Sourcing
(SSV-10)V dc
-
On-state Current
10mA
2mA
Off-state Voltage - Sinking
5V dc
-
