Rockwell Automation 1747-DCM,D17476.8 Direct Communication Module User Manual
Page 17
Chapter 1
Overview
1–3
Compatible Adapters
Catalog
Number
Device
Extended
Node
Capability
Comments
1785-LT/x
PLC-5/15
Yes
In adapter mode
1785-LT2
PLC-5/25
Yes
In adapter mode
1785-LT3
PLC-5/12
Yes
In adapter mode
1785-L30x
PLC-5/30
Yes
In adapter mode
1785-L40x
PLC-5/40
Yes
In adapter mode
1785-L60x
PLC-5/60
Yes
In adapter mode
1771-ASC
Remote I/O Adapter Module
No
1771-ASB
Remote I/O Adapter Module
Series B and
C only
Series A, B, and C
1771-AM1
1-Slot I/O Chassis with Integral
Power Supply and Adapter
Yes
1771-AM2
2-Slot I/O Chassis with Integral
Power Supply and Adapter
Yes
1784-F30D
Plant Floor Terminal Remote I/O
Expansion Module
Yes
1771-RIO
Remote I/O Interface Module
No
1771-JAB
Single Point I/O Adapter Module
Yes
1771-DCM
Direct Communication Module
No
1778-ASB
Remote I/O Adapter Module
Yes
1747-ASB
Remote I/O Adapter Module
Yes
2706-xxxx
DL40 Dataliner
t
Yes
Must be catalog number
2706-ExxxxxB1.
2705-xxx
RediPANEL
t
Yes
2711-xx
PanelView Terminal
Yes
1336-RIO
Remote I/O Adapter for 1336 AC
Industrial Drives
Yes
1395-NA
Remote I/O Adapter for 1395 DC
Industrial Drives
Yes
1747-ASB
SLC 500 Remote I/O Adapter
Module
Yes
