1756-CLX/C Module Tag List E-5
Publication 1756-UM524B-EN-P - December 2008
Local:1:O.DATA[3].17 BOOL NX31_Receive_Done.17
Local:1:O.DATA[3].18 BOOL NX31_Receive_Done.18
Local:1:O.DATA[3].19 BOOL NX31_Receive_Done.19
Local:1:O.DATA[3].20 BOOL NX31_Receive_Done.20
Local:1:O.DATA[3].21 BOOL NX31_Receive_Done.21
Local:1:O.DATA[3].22 BOOL NX31_Receive_Done.22
Local:1:O.DATA[3].23 BOOL NX31_Receive_Done.23
Local:1:O.DATA[3].24 BOOL NX31_Receive_Done.24
Local:1:O.DATA[3].25 BOOL NX31_Receive_Done.25
Local:1:O.DATA[3].26 BOOL NX31_Receive_Done.26
Local:1:O.DATA[3].27 BOOL NX31_Receive_Done.27
Local:1:O.DATA[3].28 BOOL NX31_Receive_Done.28
Local:1:O.DATA[3].29 BOOL NX31_Receive_Done.29
Local:1:O.DATA[3].30 BOOL NX31_Receive_Done.30
Local:1:O.DATA[3].31 BOOL NX31_Receive_Done.31
Local:1:O.DATA[4] DINT NX32_CPU_Slot_Number
Control Tag List (NXCT)
NXCT00_1756-CLX/C_SR_OK BOOL 1756-CLX/C Module Send/Receive OK
NXCT01_Module_Not_Ready_Error BOOL 1756-CLX/C Module cannot become
Module Ready after 5 minutes
NXCT02_Ack_Not_Received_Error BOOL NX48_Module_ Enable_Ack cannot b e
received after 5 minutes
NXCT03_Module_Not_Enabled_Error BOOL 1756-CLX/C Module cannot become
enabled after 5 minutes
NXCT04_Failed_to_ONLINE_Error BOOL 1756-CLX/C Module cannot go online
after 5 minutes
NXCT05_Initialization_Error_Reset BOOL 1 = Reset
NXCT10_Send_Request DINT Application ladder creates this signal
NXCT11_Send_Request_Pulse DINT
NXCT12_Send_Data_Strobe DINT
NXCT13_Send_Request_Delay_Pulse DINT
NXCT14_Send_Error_Reset DINT 1 = Reset
NXCT15_Send_Request_Aboarted DINT
NXCT16_Send_Error_Occured DINT
NXCT17_Send_Timeout_Error DINT NX50_Send_Done cannot be received
after 1 minute
NXCT20_Receive_Start DINT Application ladder creates this signal
Tag Name Data Type Description
