Rockwell Automation 1756-NEX Nexus Module User Manual
Page 70
D-12 1756-CLX/C Module Backplane Communication Tag List
Publication 1756-UM524B-EN-P - December 2008
NX04_Send_Handle_Param[76]
DINT
Send 12 ; Reserved
0
NX04_Send_Handle_Param[77]
DINT
Send 12 ; Reserved
0
NX04_Send_Handle_Param[78]
DINT
Send 13 ; Reserved
0
NX04_Send_Handle_Param[79]
DINT
Send 13 ; Transaction Code
<1 to 59999> <0=Not used>
0
NX04_Send_Handle_Param[80]
DINT
Send 13 ; Multicast Group Number
<1 to 255>
0
NX04_Send_Handle_Param[81]
DINT
Send 13 ; Data Size <0 to 1024>
1024
NX04_Send_Handle_Param[82]
DINT
Send 13 ; Reserved
0
NX04_Send_Handle_Param[83]
DINT
Send 13 ; Reserved
0
NX04_Send_Handle_Param[84]
DINT
Send 14 ; Reserved
0
NX04_Send_Handle_Param[85]
DINT
Send 14 ; Transaction Code
<1 to 59999> <0=Not used>
0
NX04_Send_Handle_Param[86]
DINT
Send 14 ; Multicast Group Number
<1 to 255>
0
NX04_Send_Handle_Param[87]
DINT
Send 14 ; Data Size <0 to 1024>
1024
NX04_Send_Handle_Param[88]
DINT
Send 14 ; Reserved
0
NX04_Send_Handle_Param[89]
DINT
Send 14 ; Reserved
0
NX04_Send_Handle_Param[90]
DINT
Send 15 ; Reserved
0
NX04_Send_Handle_Param[91]
DINT
Send 15 ; Transaction Code <1 to
59999> <0=Not used>
0
NX04_Send_Handle_Param[92]
DINT
Send 15 ; Multicast Group Number
<1 to 255>
0
NX04_Send_Handle_Param[93]
DINT
Send 15 ; Data Size <0 to 1024>
1024
NX04_Send_Handle_Param[94]
DINT
Send 15 ; Reserved
0
NX04_Send_Handle_Param[95]
DINT
Send 15 ; Reserved
0
NX04_Send_Handle_Param[96]
DINT
Send 16 ; Reserved
0
NX04_Send_Handle_Param[97]
DINT
Send 16 ; Transaction Code
<1 to 59999> <0=Not used>
0
NX04_Send_Handle_Param[98]
DINT
Send 16 ; Multicast Group Number
<1 to 255>
0
NX04_Send_Handle_Param[99]
DINT
Send 16 ; Data Size <0 to 1024>
1024
NX04_Send_Handle_Param[100]
DINT
Send 16 ; Reserved
0
NX04_Send_Handle_Param[101]
DINT
Send 16 ; Reserved
0
NX04_Send_Handle_Param[102]
DINT
Send 17 ; Reserved
0
NX04_Send_Handle_Param[103]
DINT
Send 17 ; Transaction Code
<1 to 59999> <0=Not used>
0
Table D.A Module Backplane Communication Tag List
Tag Name
Data
Type
Description
Initial
Value
