D-26 1756-CLX/C Module Backplane Communication Tag List
Publication 1756-UM524B-EN-P - December 2008
NX90_Received_Data_Size[31] DINT Actual Received Data Size for
Handle 31
NX91_Receive_Data_00 INT[512] Receive 0 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_01 INT[512] Receive 1 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_02 INT[512] Receive 2 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_03 INT[512] Receive 3 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_04 INT[512] Receive 4 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_05 INT[512] Receive 5 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_06 INT[512] Receive 6 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_07 INT[512] Receive 7 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_08 INT[512] Receive 8 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_09 INT[512] Receive 9 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_10 INT[512] Receive 10 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_11 INT[512] Receive 11 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_12 INT[512] Receive 12 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_13 INT[512] Receive 13 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_14 INT[512] Receive 14 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_15 INT[512] Receive 15 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_16 INT[512] Receive 16 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_17 INT[512] Receive 17 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_18 INT[512] Receive 18 ; Data Buffer / Size
< Max INT[512] >
NX91_Receive_Data_19 INT[512] Receive 19 ; Data Buffer / Size
< Max INT[512] >
Table D.A Module Backplane Communication Tag List
Tag Name Data
Type
Description Initial
Value
