1756-CLX/C Module Tag List
Tag Name Data Type Description
Local:1:C.DATA AB:1756 C:0 Control signal is not used (N/A)
Local:1:C.DATA SINT[400]
AB:1756 I:0 1756-CLX/C Connected Input
DINT[4] Connected InputDINT [4]
Local:1:I.DATA[0] DINT Reserved for System
Local:1:I.DATA[1] DINT NX40 ; Status Data Table
Local:1:I.DATA[1].0 BOOL NX40_Module_Enabled
Local:1:I.DATA[1].2 BOOL NX42_Operation_Mode
Local:1:I.DATA[1].6 BOOL NX46_System_Error
Local:1:I.DATA[1].7 BOOL NX47_Module_Ready
Local:1:I.DATA[1].8 BOOL NX48_Module_Enable_Ack
Local:1:I.DATA[2] DINT NX50_Send_Done
Local:1:I.DATA[2].0 BOOL NX50_Send_Done.0
Local:1:I.DATA[2].1 BOOL NX50_Send_Done.1
Local:1:I.DATA[2].2 BOOL NX50_Send_Done.2
Local:1:I.DATA[2].3 BOOL NX50_Send_Done.3
Local:1:I.DATA[2].4 BOOL NX50_Send_Done.4
Local:1:I.DATA[2].5 BOOL NX50_Send_Done.5
Local:1:I.DATA[2].6 BOOL NX50_Send_Done.6
Local:1:I.DATA[2].7 BOOL NX50_Send_Done.7
Local:1:I.DATA[2].8 BOOL NX50_Send_Done.8
Local:1:I.DATA[2].9 BOOL NX50_Send_Done.9
Local:1:I.DATA[2].10 BOOL NX50_Send_Done.10
Local:1:I.DATA[2].11 BOOL NX50_Send_Done.11
Local:1:I.DATA[2].12 BOOL NX50_Send_Done.12
Local:1:I.DATA[2].13 BOOL NX50_Send_Done.13
Local:1:I.DATA[2].14 BOOL NX50_Send_Done.14
Local:1:I.DATA[2].15 BOOL NX50_Send_Done.15
