D-8 1756-CLX/C Module Backplane Communication Tag List
Publication 1756-UM524B-EN-P - December 2008
Table D.A Module Backplane Communication Tag List
Tag Name
Data
Type
Description
Initial
Value
NX00_Node_Name-Param
SINT[10]
Parameters for Node_Name
- - -
NX00_Node_Name_Param[0]
SINT
1st character of Node Name
5
NX00_Node_Name_Param[1]
SINT
2nd character of Node Name
6
NX00_Node_Name_Param[2]
SINT
3rd character of Node Name
N
NX00_Node_Name_Param[3]
SINT
4th character of Node Name
E
NX00_Node_Name_Param[4]
SINT
5th character of Node Name
X
NX00_Node_Name_Param[5]
SINT
6th character of Node Name
(null)
NX00_Node_Name_Param[6]
SINT
7th character of Node Name
(null)
NX00_Node_Name_Param[7]
SINT
8th character of Node Name
(null)
NX00_Node_Name_Param[8]
SINT
9th character of Node Name
(null)
NX00_Node_Name_Param[9]
SINT
10th character of Node Name
(null)
NX01_IP_Address_Param
INT[4]
Parameters for IP_Address
- - -
NX01_IP_Address_Param[0]
INT
1st character of IP Address
192
NX01_IP_Address_Param[1]
INT
2nd character of IP Address
168
NX01_IP_Address_Param[2]
INT
3rd character of IP Address
0
NX01_IP_Address_Param[3]
INT
4th character of IP Address
1
NX02_Subnet_Mask_Param
INT[4]
Parameters for Subnet_Address
- - -
NX02_Subnet_Mask_Param[0]
INT
1st character of Subnet Mask
255
NX02_Subnet_Mask_Param[1]
INT
2nd character of Subnet Mask
255
NX02_Subnet_Mask_Param[2]
INT
3rd character of Subnet Mask
255
NX02_Subnet_Mask_Param[3]
INT
4th character of Subnet Mask
0
NX03_Node_Param
DINT[16]
Parameters related to Node
- - -
NX03_Node_Param[0]
DINT
Logical Node Number <1 to 4095>
1
NX03_Node_Param[1]
DINT
Local Data Field Number <1 to 255> 1
NX03_Node_Param[2]
DINT
Node Mode at Startup
NX03_Node_Param[3]
DINT
Reserved
0
NX03_Node_Param[4]
DINT
Message Send Port Number
<0 - 65535 >
10000
NX03_Node_Param[5]
DINT
Node Alive Receive Port Number
<1 - 65534 >
10001
NX03_Node_Param[6]
DINT
Node Alive Interval <1 - 3600>
20
NX03_Node_Param[7]
DINT
Node Alive Count <2 - 100>
4
NX03_Node_Param[8]
DINT
Reserved
0
NX03_Node_Param[9]
DINT
Reserved
0
