POINTBlock dc 8 Input/8 Relay Output Module 19
Publication 1734-IN021C-EN-P - September 2006
Output Specifications
Attribute Value
Relay Type Form A, normally open, Single Pole, Single Throw
Output Voltage Range,
Resistive 5…28.8V dc @ 2.0 A
48V dc @ 0.5 A
125V dc @ 0.25 A
125V ac @ 2.0 A
240V ac @ 2.0 A
Relay Output Current
Rating, Inductive 2.0 A steady state @ 5…28.8V dc, L/R - 7 ms
0.5 A steady state @ 48V dc, L/R = 7 ms
0.25 A steady state @ 125V dc, L/R = 7 ms
2.0 A steady state, 15 A make @ 125V ac, PF = cos
θ = 0.4
2.0 A steady state, 15 A make @ 240V ac, PF = cos
θ = 0.4
Relay Output Current
Rating, Resistive 2 A @ 5…30V dc
0.5 A @ 48V dc
0.25 A @ 125V dc
2 A @ 125V ac
2 A @ 240V ac
Power Rating, Max,
For Resistive Loads 250 W for 125V ac
480 W for 240V ac
60 W for 28.8V dc
24 W for 48V dc
31 W for 125V dc
Power Rating, Max,
For Inductive Loads 250 VA for 125V ac
480 VA for 240V ac
60 VA for 28.8V dc
24 VA for 48V dc
31 VA for 125V dc
Load 10 mA per point min
Initial Contact Resistance 30 m
Ω
Switching Frequency 1 operation/3 s at rated load
Bounce Time 1.2 ms mean
