18 POINTBlock dc 8 Input/8 Relay Output Module
Publication 1734-IN021C-EN-P - September 2006
Input Specifications - IEC 3 24V dc Input Compliant
(1)
Attribute Value
On-state Voltage Range,
Min 10V dc
On-state Voltage Range,
Nom 24V dc
On-state Voltage Range,
Max 28.8V dc
On-state Current, Min 2.5 mA
On-state Current, Nom 6.3 mA @ 24V dc
On-state Current, Max 7.6 mA
Off-state Voltage, Max 5V dc
Off-state Current, Max 1.5 mA
Input Impedance, Max 5.3 K
Ω
Input Delay Time
OFF to ON
ON to OFF 0.5 ms hardware + (0…65 ms selectable)
0.5 ms hardware + (0…65 ms selectable)
(1)
IEC denotes the International Electrotechnical Commission.
