Analog Output Module 18
Publication 1771-IN044C-EN-P - October 2002
Value Description
Enclosure Type Rating None (open-style)
Keying Between 10 and 12
Between 26 and 28
Field Wiring Arm Catalog No. 1771ĆWC
Field Wiring Arm Screw Torque 7-9 pound-inches (0.6-0.7Nm)
Conductors Wire Size
Category
12 gauge (4mm 2 ) maximum stranded copper wire,
(Belden 8761)
3/64 inch (1.2mm) insulation maximum
2 1
Certifications
(when product is marked)
UL UL Listed Industrial Control Equipment
CSA CSA Certified Process Control Equipment for
Class I, Division 2 Group A, B, C, D Hazardous
Locations
CSA CSA Certified Process Control Equipment
CE 2 European Union 89/336/EEC EMC Directive,
compliant with:
EN61000-6-4, Industrial Emissions
EN50082-2, Industrial Immunity
EN61326, Meas./Control/Lab., Industrial
Requirements
EN61000-6-2, Industrial Immunity
EEx 2 European Union 94/9/EEC ATEX Directive, compliant
with:
EN50021, Potentially Explosive Atmospheres,
Protection n"
C-Tick 2 Australian Radiocommunications
Act,compliant with AS/NZS 2064, Industrial
Emissions
User Manual Publication 1771ĆUM030
1 Use this conductor category information for planning conductor routing . Refer to publication 1770Ć4.1, Industrial
Automation Wiring and Grounding Guidelines."
2 See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates and other
certification details
