Determine module slot location – Rockwell Automation 1756-ENBT ControlLogix EtherNet/IP Bridge Module Installation Instructions User Manual
Page 9
ControlLogix EtherNet/IP Bridge Module 9
Publication
1756-IN019C-EN-P - November 2004
Determine Module Slot Location
You can install the module in any slot in the ControlLogix chassis. You can
also install multiple 1756-ENBT modules in the same chassis. The figure
below shows chassis slot numbering in a 4-slot chassis. Slot 0 is the first slot
and is always the leftmost slot in the rack (the first slot to the right of the
power supply).
Power Supply
Slot 0
Slot 1
Slot 2
Slot 3
Chassis
