Rockwell Automation 1756-ENBT ControlLogix EtherNet/IP Bridge Module Installation Instructions User Manual
Page 19
ControlLogix EtherNet/IP Bridge Module 19
Publication
1756-IN019C-EN-P - November 2004
Shock,
Non-operating
IEC60068-2-27 (Test Ea, Unpackaged shock):
50g
Emissions
CISPR 11:
Group 1, Class A
ESD Immunity
IEC 61000-4-2:
6kV contact discharges
8kV air discharges
Radiated RF
Immunity
IEC 61000-4-3:
10V/m with 1kHz sine-wave 80%AM from 30MHz to 2000MHz
10V/m with 200Hz 50% Pulse 100%AM at 900Mhz
10V/m with 200Hz 50% Pulse 100%AM at 1890Mhz
EFT/B Immunity
IEC 61000-4-4:
±2kV at 5kHz on communications ports
Surge
Transient
Immunity
IEC 61000-4-5:
±2kV line-earth(CM) on communications ports
Conducted RF
Immunity
IEC 61000-4-6:
10Vrms with 1kHz sine-wave 80%AM from 150kHz to 80MHz
Enclosure Type
Rating
None (open-style)
