Identify module components – Rockwell Automation 1756-ENBT ControlLogix EtherNet/IP Bridge Module Installation Instructions User Manual
Page 7
ControlLogix EtherNet/IP Bridge Module 7
Publication
1756-IN019C-EN-P - November 2004
Identify Module Components
Use the following figure to identify the external features of the module.
LINK NET OK
31272-M
Backplane
Connector
Front View
Front
Panel
MAC ID
Label
Side View
(Inside)
Bottom View
Front
of
Module
RJ45 Cable
Connector located
on underside of module
Backplane
Connector
