ControlLogix EtherNet/IP Bridge Module 11

Publication

1756-IN019C-EN-P - November 2004

Remove or Replace the Module (when applicable)

IMPORTANT

If you are replacing an existing module with an
identical one, and you want to resume identical
system operation, you must install the new
module in the same slot.

31277-M

31278-M

Push on upper and lower module tabs
to disengage them.

Slide module out of chassis.
