8 Program Storage Device
Publication 1747-IN001C-EN-P - May 2006
Program Transfer between the Program Storage Device and Controller
If you want to transfer a program to the controller and the controller is not in
Remote Program mode, follow the steps using the mode change command.
1. Without pressing the pushbutton, slide the selector switch from the
OFF/NEXT CMD position to the desired command.
2. Wait until the green LED indicator illuminates steadily.
3. Within 10 seconds after the green LED indicator illuminates steadily, press
the pushbutton.
4. Release the pushbutton within 10 seconds.
While the command is executing, the green LED indicator flashes.
If the green LED indicator and red LED indicator flash simultaneously, refer
to the Incompatibilities section.
When execution is complete, either the green or the red LED indicator
illuminates steadily for 30 seconds. Green indicates a successful transfer and
red indicates a failed transfer.
After 30 seconds, the illuminated LED indicator turns off, and the program
storage device enters the Sleep mode.
Program Transfer between the Program Storage Device and Controller
Switch Position Function
To PLC Transfers a new program from the program storage device to the controller. The
controller must be in Remote Program mode or an error will occur.
Mode Change Toggles the controller mode between Remote Program and Remote Run. When the
program storage device switches the controller to Remote Program, the error bits are
cleared.
From PLC Transfers a program from the controller to the program storage device. The program
storage device can receive a program regardless of the controller’s operating mode.
Download
Upload
To PLC
From PLC
SLC 5/03, 5/04, and 5/05 controller
MicroLogix 1000, 1100, 1200, and 1500 controller
PSD
Industrial Programming Station with
RSLogix 500 software,
A.I. 500 software, or Advanced
Programming Software.
