4 Program Storage Device
Publication 1747-IN001C-EN-P - May 2006
The program storage device supports DF1 full-duplex with CRC or BCC error
detection, 8 data bits, 1 stop bit, and no parity at communication rates 1200 bps,
2400 bps, 4800 bps, 9600 bps, 19200 bps, and 38400 bps. During operation, the
program storage device matches the DF1 communication rate of the SLC or
MicroLogix controller. The program storage device will not communicate with a
controller if the channel is configured for DH485, DF1 half-duplex or ASCII
protocol. Embedded responses and simultaneous communications are not
supported.
The program storage device checks for 19200 bps communication rate first. Use
19200 bps for fastest recognition.
Controllers used with 1747-PSD Program Storage Device
Controller Series Operating System
SLC 5/03 Not applicable OS300
OS301
OS302
SLC 5/04 OS400
OS401
SLC 5/05 OS500
OS501
MicroLogix 1000 Analog A Not applicable
MicroLogix 1000 Discrete A, B, C, D, E, and F
MicroLogix 1100 (1)
(1) Recipe data and/or Data Logs stored in Data Log Memory cannot be uploaded or downloaded by the 1747-PSD
programming device.
A
MicroLogix 1200 A, B, and C
MicroLogix 1500, 1764-LSP A, B, and C
MicroLogix 1500, 1764-LRP
(1) B and C
PC-based industrial programming
station Not applicable RSLogix 500, A.I. 500 Series, SLC 500
Advanced Programming Software
