18 Stratix 6000 Ethernet Managed Switches
Rockwell Automation Publication 1783-IN004B-EN-P - June 2014
Specifications
Stratix 6000 Ethernet Managed Switches
Attribute 1783-EMS08T 1783-EMS04T
Power requirements 12…48V DC
Class 2/SELV
250 mA @ 24V DC 12…48 V DC
Class 2/SELV
100 mA @ 24V DC
Power dissipation 5.8 W @ 60 °C (140 °F) max 2.6 W @ 60 °C (140 °F) max
Thermal dissipation 24.6 BTU/hr @ 60 °C (140 °F) max
Network ports 8 RJ-45 10/100 full/half duplex ports,
optional SFP transceiver port 4 RJ-45 10/100 full/half duplex ports
Protocols TCP/IP, EtherNet/IP, Telnet, Http, DHCP, BOOTP, FTP, IGMP, SMTP
Indicators 16 port indicators,
3 status indicators 8 port indicators,
2 status indicators
EtherNet/IP features MAC ID management, bandwidth alarming, port control, link status, scaled
bandwidth information,
connections active
Switch features VLAN, IGMP snooping, IGMP query V1
and V2, DHCP server, BOOTP server,
QoS, port mirroring
IGMP snooping, IGMP query V1 and V2,
DHCP server, BOOTP server, QoS, port
mirroring
Options 1 gigabyte fiber optic transceiver —
Voltage variation IEC 61000-4-29:
10 ms interruption on DC supply ports
Enclosure type rating Meets IP20
Inrush current, max 2.2 A
Isolation voltage 50 V (continuous), Basic Insulation Type
No isolation between individual Ethernet ports
Routine tested at 707V AC for 1 s, DC power ports to ground and DC power ports to
Ethernet ports
