4 1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules
Publication 1732E-IN006C-EN-E - June 2013
Additional Resources
If you would like a manual, you can:
•
download a free electronic version from the internet:
•
purchase a printed manual by contacting your local Allen-Bradley distributor or
Rockwell Automation representative
Overview
The EtherNet/IP ArmorBlock is a 24V DC I/O module that communicates via
EtherNet/IP. The sealed IP65, IP67 and IP69K housing of these modules requires no
enclosure. Note that environmental requirements other than IP65, IP67 and IP69K may
require an additional appropriate enclosure. I/O connectors are micro M12 style.
EtherNet/IP networks use advanced network technology, for example,
producer/consumer communication, to increase network functionality and throughput.
For detailed information about features, functionality, and configuration requirements
and procedure for the 1732E-IF4M12R, 1732E-OF4M12R modules, see the 1732E
ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules User
Manual, publicatio
Resource
Description
1732E ArmorBlock™ Dual-Port EtherNet/IP 4-Point
Analog Modules Wiring Diagrams
Pinout guide wiring diagram for the ArmorBlock
dual-port EtherNet/IP 4-Point Analog modules
(1732E-IF4M12R, 1732E-OF4M12R,
1732E-IT4IM12R, 1732E-IR4IM12R).
1732E ArmorBlock Dual-Port EtherNet/IP 4-Point
Analog Input and Output Modules User Manual
A detailed description of module functionality,
configuration, installation procedure and
information on how to use the ArmorBlock
dual-port EtherNet/IP 4-Point Analog Input and
Output modules (1732E-IF4M12R,
1732E-OF4M12R).
Industrial Automation Wiring and Grounding
Guidelines, publication
.
More information on proper wiring and grounding
techniques.
