1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules 21
Publication 1732E-IN006C-EN-E - June 2013
Output Specifications – 1732E-OF4M12R
Attributes
Value
Number of outputs
4
Resolution, min
16 bits
Data format
16-bit sign magnitude
Conversion rate
< 2 ms
Output type
Configurable as voltage or current per channel
Output range
Current output
Voltage output
0…20 mA, 4…20 mA
+/-10V, 10 mW
Short circuit protection, max
Current output
Voltage output
20 mA (0…20 mA mode)
20 mA per channel
Accuracy
0.1% Full Scale @ 25 °C (77 °F)
Accuracy drift with temperature, max
40 ppm % Full Scale /°C @ 25 °C (77 °F)
Calibration
Factory calibrated. Calibration is also supported through
RSLogix 5000.
Environmental Specifications
Attribute
Value
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…60 °C (-4…140 °F)
Temperature, nonoperating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
Temperature, ambient, max
60 °C (140 °F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% noncondensing
Vibration
IEC60068-2-6 (Test Fc, Operating):
5 g @ 10…500 Hz
Shock, operating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
