18 1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules
Publication 1732E-IN006C-EN-E - June 2013
Indicator Status for Modules
Indicator
Status
Description
Module status
Off
No power applied to the device.
Flashing
red/green
The module is performing POST (Power-On Self Test), which
completes within 30 s.
Green
Device operating normally.
Flashing red
Module has experienced a recoverable fault.
Red
Unrecoverable fault – may require device replacement.
Network status
Off
The device is not initialized or the module does not have an
IP address.
Flashing green
The device has no CIP connections. The device has an IP
address, but no CIP connections are established.
Green
Device is online, has an IP address. CIP connections are
established.
Flashing red
One or more connections have timed out.
Red
The module has detected that its IP address is
already in use.
Flashing
red/green
The module is performing a power-on self test (POST).
Network link status
(Link 1/Link 2)
Off
No link established.
Green
Link established on indicated port at 100 Mbps.
Flashing green
Link activity present on indicated port at 100 Mbps.
Yellow
Link established on indicated port at 10 Mbps.
Flashing yellow
Link activity present on indicated port at 10 Mbps.
Auxiliary
Power status
Off
Auxiliary power off or not connected.
Green
Auxiliary power applied to device.
