20 1732E ArmorBlock Dual-Port EtherNet/IP 4-Point Analog Input and Output Modules
Publication 1732E-IN006C-EN-E - June 2013
Dimensions, approx., HxWxD
179 x 37 x 27 mm (7.05 x 1.46 x 1.06 in.)
Weight, approx.
0.34 kg (0.75 lb)
Wiring category
(1)
1 – on signal ports
1 – on power ports
1 – on communication ports
(1)
Use this Conductor Category information for planning conductor routing. Refer to publication
Industrial Automation Wiring and Grounding Guidelines.
Input Specifications – 1732E-IF4M12R
Attributes
Value
Number of inputs
4
Resolution, min
16 bits
Data format
16-bit sign magnitude
Conversion rate
1.005 kHz per channel
Input type
Configurable as voltage or current inputs
Notch Filter
1 kHz per channel
Input range
Current input
Voltage input
0…20 mA, 4…20 mA
0…10V, 0…5V
±5V, ±10V (bipolar range)
Input impedance
125 k
Ω
per channel
Accuracy
0.1% Full Scale @ 25 °C (77 °F)
Accuracy drift with temperature, max
40 ppm % Full Scale /°C @ 25 °C (77 °F)
Calibration
Factory calibrated. Calibration is also supported through
RSLogix 5000.
Overload support
Current input
Voltage input
32 mA
30V continuous
