Programming

Chapter 3

3Ć36

Error Message

If you enter a BCD number larger than 4095, the error bit (bit 14) is set and the
result reads zero.

AF1 Binary to BCD Conversion Function

The AF1 binary to BCD conversion function converts a 12-bit binary number to
a BCD number (from 0 to 4095).

How to Enter an AF1 Binary to BCD Conversion Function

To program an AF1 binary to BCD conversion function, perform the following
steps:

1.

Press [SHIFT] [EAF] or [SHIFT] [SCT] on the keyboard of your
industrial terminal. Figure 3.1 appears on the CRT.

2.

Enter 14, the function number for the AF1 binary to BCD conversion
function.

This entry identifies that the function entered is to perform an AF1 binary to
BCD conversion and that the processor use the data table format shown in
Figure 3.34 when executed.

Figure 3.34

General AF1 Binary to BCD Conversion Function Word and Digit Format

17 16 15 14 13 12 11 10 7 6 5 4 3 2 1 0

S

Digit 1 (MSD)

(Always = 0)

Digit 3

Bit No.

Data Address

Digit 5

S

Result Address

Result

D

E

E = Enable Bit (1 = Function in Progress)

S = Sign Bit (1= Negative)

D = Done Bit (1 = Function Complete)

MSD = Most Significant Digit

LSD = Least Significant Digit

11496

m

n + 1

n

Operand

Digit 4

Digit 6

(LSD)

Digit 2

(Always = 0)

12 Bit Binary Number
